Coldstream concrete Projects
Clare Ave Extension
In the fall of 2015 Coldstream Concrete supplied a project to Gibbons Contracting Ltd in the City of Welland, Ontario. It consisted of a double run – open bottom box culvert with a span of 7.316m and a rise of 1.524m. The 9.0m wide road joined two subdivisions together in an area with extreme high water tables and poor soils. This all precast job consisted of 24 precast footing units, 24 precast open bottom box units and 8 different sized wing wall units. The total precast installation time in late fall was 3 days.
Bridge 417 – Thompson Line
Central Elgin County
On October 15, 2015 Coldstream Concrete supplied an open bottom precast culvert that had a 11.5m span and 3.5m rise to the County of Central Elgin. Relatively dry conditions were very helpful during the installation due to the size of the watercourse and excavation. The culvert consisted of 15 units to create a 16m wide roadway. This single structure replaced a design for a dual box culvert. This is turn reduced the total project cost and created better watercourse flow. Coldstream also supplied precast concrete footings. The total installation time for footing and bridge elements was under 2 day.
Chinnick Drain and Pump Station
In June 2015 Coldstream Concrete supplied 2 large pump stations that were 7.2m x 3.8m x 6.2m deep to the Chinnick Drain and Pump project in the Municipality of Chatham Kent. These chambers house pump intakes and collect water from the Chinnick Drain which is then pumped into Lake St. Clair. The entire one end was open to receive water from the drain. Due to the high water levels buoyancy issues had to be considered. The 3 walled chamber caused structural problems. This was remedied by inserting 25m rebar into preformed vertical tubes that extended through all the riser sections, base and cap. This created horizontal and vertical reinforcing grid and joined all the elements together. Each chamber consisted of 9 units. All 18 united were installed in the winter with water issue over 1.5 days.
On May 23, 2018 Coldstream Concrete Ltd. supplied a seven-piece precast concrete trench complete with approach slabs and maintenance chamber to the Ormston Subdivision in Kitchener, Ontario. The trench and all of its components were constructed using epoxy reinforcement and came equipped with concrete corbels on either side to support the precast approach slabs. Each trench piece has 6 separate galvanized steel angles cast into the concrete corners for protection and roadway grating. The trench was installed and backfilled in less than two days.
On July 11th Coldstream Concrete Ltd. supplied a 12-piece “all skewed box culvert” for the town of Plympton-Wyoming. Each piece of he 3.6m span by 2.1m rise box culvert was constructed on a 30-degree skew. This was done in order to avoid large/heavy end units which are typical for precast skewed end culverts. Due to the fact that all pieces were designed to the same physical dimension (without large heavy end units), all 12 pieces were installed quickly and safely by 2pm the day they were delivered.
Grey Rd 10
Grey County, Ontario
On June 19th 2018 Coldstream Concrete Ltd. supplied a ten-piece open-bottom precast concrete culvert to Wayne Schwartz Construction Ltd. (Miller Group) in Grey County, Ontario. The culvert spans 5.5m and sits 2.5m tall. In typical precast fashion it was installed in less than one day, resulting in shorter road closure times for the public. The second phase is set to be installed in mid August which includes a second precast culvert with similar properties of 10 + 590.
Rock Glen Road
Municipality of Lambton Shores, Ontario
On September 14, 2018, Coldstream Concrete Ltd. supplied a large box culvert (6m span x 2.4m rise) to the Municipality of Lambton Shores. The culvert consisted of 8 standard box units weighing 83,400 lbs each, and 1 end unit with a skew of 35o weighing 87,600 lbs. The skewed end unit was surrounded on both sides by the London Boulder Block retaining wall system (also produced by Coldstream Concrete). This system always provides an easy and decorative finish to any culvert. All 9 pieces were installed in half a day, and back-filled later the same day. The waterway was back up and running by the start of the following day.
